| Specifications* |
t128E-16 |
t064E-16 |
t064V-8 |
t032H-2 |
t016H-1 |
| Description |
FlexCam 16
HDD/128ch NVR with
RAID Support |
FlexCam 16 HDD/64ch
NVR with RAID
Support |
FlexCam 8 HDD/ 64ch
NVR with RAID
Support |
FlexCam 2 HDD/32ch
NVR |
FlexCam 1 HDD/16ch
NVR |
| Operating System |
Linux OS |
| Camera Inputs |
128ch |
64ch |
64ch |
32ch |
16ch |
| Video Resolution |
16MP/12MP/8MP/6MP/5MP/
4MP/3MP/1080P/1280×1024/
960P/720P/960H/D1/CIF |
16MP/12MP/8MP/6MP/5MP/
4MP/3MP/1080P/1280×1024/
960P/720P/960H/D1/CIF |
16MP/12MP/8MP/6MP/5MP/
4MP/3MP/1080P/1280×1024/
960P/720P/960H/D1/CIF |
12MP/9MP/8MP/6MP/5MP/
4MP/3MP/1080P/1280×1024/
960P/720P/960H/D1/CIF |
8MP/6MP/5MP/4MP/3MP/
1080P/1280×1024/960P/720P/
960H/D1/CIF |
Network Bandwidth
|
768 Mbps (Incoming)
768 Mbps (Outgoing) |
640 Mbps (Incoming)
640 Mbps (Outgoing) |
640 Mbps (Incoming)
640 Mbps (Outgoing) |
320Mbps (Incoming)
256Mbps(Outgoing) |
160Mbps (Incoming)
160Mbps (Outgoing) |
| Video Compression |
H.264/H.265/H.265+/H.265S |
Live View Decoding
|
1x 16MP@30fps / 4x 12MP@30fps (main output only) |
1x 16MP@30fps / 4x 12MP@30fps (main output only) |
1x 16MP@30fps / 4x 12MP@30fps (main output only) |
1x 12MP@20fps /
4x 1080P@30fps
|
1x 8MP@30fps /
6x 1080P@30fps |
Playback Decoding
|
1x 16MP@30fps / 4x 12MP@30fps (main output only) |
1x 16MP@30fps / 4x 12MP@30fps (main output only) |
1x 16MP@30fps / 4x 12MP@30fps (main output only) |
1x 12MP@20fps /
4x 1080P@30fps
|
1x 8MP@30fps /
6x 1080P@30fps |
| Simultaneous Playback |
16ch Max |
Recording
|
16MP@3840fps (30fps per channel) |
16MP@1920fps (30fps per channel) |
16MP@1920fps (30fps per channel) |
12MP@640fps (20fps per channel) /
9MP@960fps (30fps per channel)
|
8MP@480fps (30fps per channel)
|
Audio Input
|
128ch IPC Audio Input, 1x RCA |
64ch IPC Audio Input, 1x RCA |
16ch IPC Audio Input, 1x RCA |
32ch IPC Audio Input, 1x RCA
|
16ch IPC Audio Input, 1x RCA |
Audio Output
|
1x RCA, HDMI |
1x RCA, HDMI |
1x RCA, HDMI |
1x RCA |
1x RCA |
Video Output
|
HDMI1: 8K/4K/1080P/SXGA/XGA
HDMI2/3: 4K/1080P/SXGA/XGA
HDMI4: 1080P/SXGA/XGA
VGA: 1080P/SXGA/XGA (Video output same as HDMI1) |
HDMI1: 8K/4K/1080P/SXGA/XGA
HDMI2/3: 4K/1080P/SXGA/XGA
HDMI4: 1080P/SXGA/XGA
VGA: 1080P/SXGA/XGA (Video output same as HDMI1) |
HDMI1: 8K/4K/1080P/SXGA/XGA
HDMI2/3: 4K/1080P/SXGA/XGA
HDMI4: 1080P/SXGA/XGA
VGA: 1080P/SXGA/XGA (Video output same as HDMI1) |
HDMI1: 4K/1080P/SXGA/XGA
HDMI2: 1080P/SXGA/XGA
VGA: 1080P/SXGA/XGA
(Video output same as HDMI1) |
HDMI1: 4K/1080P/SXGA/XGA
VGA: 1080P/SXGA/XGA |
USB Interface
|
2x Rear (USB3.0 & USB2.0), 2x Front (USB2.0) |
2x Rear (USB3.0 & USB2.0), 2x Front (USB2.0) |
2x Rear (USB3.0 & USB2.0), 1x Front (USB2.0) |
2x Rear (USB3.0 & USB2.0), 1x Front (USB2.0) |
1x Rear, 1x Front (USB2.0) |
| Protocol |
ONVIF, TCP/IP, HTTP, HTTPS, 802.1x, FTP, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, IPv4, UDP, WebSocket, PPPoE, SNMP, IGMP
|
Gigabit Ethernet
|
2x RJ45 |
2x RJ45 |
2x RJ45 |
2x RJ45 |
1x RJ45 |
Storage Capacity
|
16x 10TB SATA HDD, 2x eSATA HDD |
16x 10TB SATA HDD, 2x eSATA HDD |
8x 10TB SATA HDD, 2x eSATA HDD |
2x 10TB SATA HDD |
1x 10TB SATA HDD |
RAID
|
RAID 0/1/5/6/10 |
RAID 0/1/5/6/10 |
RAID 0/1/5/6/10 |
No |
No |
Alarm Input / Output
|
24x Inputs / 8x Outputs |
24x Inputs / 8x Outputs |
16x Inputs / 4x Outputs |
8x Inputs / 4x Outputs |
No |
| Remote Viewer |
CMS, Web Client, Android, iOS |
Face Detection
|
128ch (AI by IPC) / 4ch (AI by NVR) |
64ch (AI by IPC) / 4ch (AI by NVR) |
64ch (AI by IPC) / 4ch (AI by NVR) |
32ch (AI by IPC) / 2ch (AI by NVR) |
16ch (AI by IPC) / 2ch (AI by NVR) |
Face Match
|
16ch |
16ch |
16ch |
6ch |
No |
Face Comparison Capability
|
36 picture/sec |
36 picture/sec |
36 picture/sec |
18 picture/sec |
No |
Face Comparison Alarm
|
Face Recognition / Stranger |
Face Recognition / Stranger |
Face Recognition / Stranger |
Face Recognition / Stranger |
No |
Face Picture Database
|
10,000 |
10,000 |
10,000 |
10,000 |
No |
Face Search
|
Yes |
Yes |
Yes |
Yes |
No |
| Human/Vehicle Classification |
Yes |
| License Plate Recognition |
Yes (AI by IPC) |
| Other VCA |
Object Abandoned/Missing, Line Crossing, Region Intrusion/Entrance/Exiting, Target Counting (Human/Vehicle/Bike), Heat Map, Loitering Detection, Illegal Parking Detection |
Rack Mount Size
|
3U |
3U |
2U |
1U |
No |
Power
|
ATX-275W (50W Max, without HDD) |
ATX-275W (50W Max, without HDD) |
ATX-200W (50W Max, without HDD) |
DC12V, 4A (20W Max, without HDD) |
DC12V, 1.5A (10W Max, without HDD) |
Dimensions,
W x H x D (mm)
|
437.0 × 143.0 x 483.0 |
437.0 × 143.0 x 483.0 |
445.0 × 90.0 x 436.0 |
380.0 x 45.0 x 268.0 |
300.0 x 48.1 x 248.5 |
| Operating Environment |
-10°C~50°C, Up to 90% RH |
